인스파이어 시리즈 343

43 STOPS

교회, 콘서트 홀을 위한 이상적인 오르간

인스파이어 시리즈 343에는 43개의 조명이 들어오는 스탑 탭, 그리고 버리언트 라이브러리와 18개의 오케스트라 셀렉션으로 구성된 총 233개의 보이스가 준비되어 있습니다. 3개의 벨로시티 센서티브 건반 매뉴얼, 32음 AGO 페달 보드 및 6.2 플러스 2채널 안티포널 익스터널 오디오 시스템으로 확장할 수 있는 내부 2.1 오디오 시스템을 갖추었습니다. 인스파이어 시리즈 343은 끝없는 유연성을 요구로 하는 교회와 콘서트 오르간에 이상적입니다.

네 가지 오르간 스타일

스탠더드 스탑 리스트인 American Eclectic 외에도 English Cathedral, French Romantic, German Baroque 총 4가지 중에서 스탑 리스트를 선택할 수 있습니다. 또한 버리언트 라이브러리는 원하는 대로 선택할 수 있는 추가 스탑으로 구성됩니다. 또한 연주 시 한 가지 스타일의 스탑에 국한되지 않고 모두 즉시 사용 가능합니다. 다양한 음색을 유연하게 사용하고자 하는 오르가니스트에세 인스파이어 343은 이상적인 오르간입니다.

안티포널 스위칭

ANTIPHONAL SWITCHING

인스파이어 시리즈 343에서 괄목할 만한 편의 기능은 안티포널 스위칭입니다. 이 기능은 청중이 오르간에서 어느 정도 물리적으로 떨어져 있을 수 있는 넓은 공간에서도 제대로 울리는 사운드를 느낄 수 있습니다. 음악적 효과를 위해 이 안티포널 스위칭 버튼을 눌러 다방향으로 오르간 사운드를 내거나 공간의 후면 또는 전면에서만 사운드를 낼 수도 있습니다.

교회, 콘서트 홀을 위한 이상적인 오르간

RDG240_Inspire_343_900x900px2
RDG240 Inspire 343 1000x900px3
previous arrowprevious arrow
next arrownext arrow
Shadow

인스파이어 343 제원

제원
편의 사항
스탑 리스트
라이브러리

VOICES

43 stops / 233 total voices
4 unique organ styles + Variant Library
215 Voice Palette™ voices
18 orchestral voices

KEYBOARDS

Velocity-sensitive “Pipe Organ Feel” tracker touch keyboards

PEDALBOARD

Velocity-sensitive 32-note AGO pedalboard

GENERAL PISTONS

10

TOE PISTONS

10 (4 more optional)

DIVISIONAL PISTONS

5 Great, 5 Swell, 5 Choir, 5 Pedal

COUPLERS

6 (Great to Pedal, Swell to Pedal, Choir to Pedal, Swell to Great, Choir to Great, Swell to Choir)
8 Orchestral Couplers (2 x Great, 2 x Swell, 2 x Choir, 2 x Pedal)
Bass Coupler
2 Melody Couplers

TREMULANTS

3 (Great, Swell, Choir)

SHOES

Great, Choir, Pedal expression
Swell expression
Crescendo

MEMORY

50 levels x 30 pistons (1500)

외형 치수

높이 : 124.5 cm
너비 : 152.4 cm
깊이 : 75.9 cm
깊이(페달보드 포함) : 118.1 cm

  • Traditional wood veneer cabinet with deluxe wood tambour
  • Available in light, medium and dark oak veneer
  • Tab stop controls
  • Record/playback with STOP, PLAY, REC pistons
  • USB-enabled for unlimited storage of registration data and saved performances
  • Hymn Player automatically plays 350 built-in hymns with introduction & verse or Prelude mode
  • Bench in matching finish
  • Rolltop + lock
  • 32-note radiating AGO pedalboard velocity-sensitive for orchestral voices
  • Self-contained pedalboard mechanism for great reliability on uneven flooring or carpeting
  • Kick switch programmable as Off, Next, Prev, Sustain and Gospel Rotor for orchestral voices
  • Programmable pedal F# sustain function for orchestral voices
  • Memory +/- pistons
  • 9 historic temperaments
  • Tuning control
  • -6/+5 transposer
  • True Sound Space: 12 real reverb environments
  • Stereo headphone jack
  • 2 x 1/4" Line Inputs
  • 2 x 1/4" Line Outputs
  • MIDI In and Out Connections
  • 2.1-channel internal audio system: 2 channels x 50 watts fullrange audio + 1 channel x 160 watts subwoofer
  • 5 loudspeakers using coaxials for a rich and highly defined sound
  • 8-channel external audio outputs
  • 2-channel audio system for external loudspeakers (optional)
  • Onboard voicing finishing and leveling controls
  • Internal Audio OFF, Main OFF, Antiphonal ON
  • Pipe organ modeling technologies
  • Great/Pedal Enclosed
  • Organ Type piston instantly activates American Eclectic, English Cathedral, French Romantic or German Baroque stops
  • Adjustable tremulants

Great

AMERICAN ECLECTIC
  • Violone 16
  • Principal 8
  • Bourdon 8
  • Gamba 8
  • Erzähler Céleste II 8
  • Octave 4
  • Spitzflöte 4
  • Super Octave 2
  • Cornet V
  • Fourniture IV
  • Trumpet 8
  • Great Orch A
  • Great Orch B
  • Tremulant
  • Swell to Great
  • Choir to Great
ENGLISH CATHEDRAL
  • Open Diapason 16
  • Open Diapason 8
  • Chimney Flute 8
  • Second Diapason 8
  • Salicional 8
  • Principal 4
  • Waldflute 4
  • Fifteenth 2
  • Cornet IV
  • Mixture IV
  • Tromba 8
FRENCH ROMANTIC
  • Montre 16
  • Montre 8
  • Bourdon 8
  • Flûte Harmonique 8
  • Gambe 8
  • Prestant 4
  • Flute Ouverte 4
  • Doublette 2
  • Cornet IV
  • Fourniture IV
  • Trompette 8
GERMAN BAROQUE
  • Prinzipal 16
  • Prinzipal 8
  • Rohrflöte 8
  • Quintatön 8
  • Salicional 8
  • Oktave 4
  • Gemshorn 4
  • Super Oktave 2
  • Kornett V
  • Mixtur VI
  • Trompete 8
VARIANT LIBRARY
  • Quintaton 16
  • Diapason 8
  • Clarabel Flute 8
  • Doppel Flute 8
  • Voix des Anges II 8
  • Harmonic Flute 4
  • Quint 2-2/3
  • Harmonic Piccolo 2
  • Terz 1-3/5
  • Cymbel III
  • French Horn 8

SWELL

AMERICAN ECLECTIC
  • Bourdon Doux 16
  • Diapason 8
  • Bourdon 8
  • Viola Céleste II 8
  • Octave 4
  • Flute Traverse 4
  • Nazard 2-2/3
  • Block Flute 2
  • Tierce 1-3/5
  • Plein Jeu IV
  • Double Trumpet 16
  • Trumpet 8
  • Oboe 8
  • Swell Orch A
  • Swell Orch B
  • Tremulant
ENGLISH CATHEDRAL
  • Bourdon 16
  • Horn Diapason 8
  • Stopped Diapason 8
  • Viole Céleste II 8
  • Octave Gamba 4
  • Flute 4
  • Quintflute 2-2/3
  • Lieblich Piccolo 2
  • Seventeenth 1-3/5
  • Mixture III
  • Trombone 16
  • Trumpet 8
  • Cornopean 8
FRENCH ROMANTIC
  • Dulciane 16
  • Montre 8
  • Bourdon 8
  • Viola Céleste II 8
  • Prestant 4
  • Flûte Octaviante 4
  • Nasard 2-2/3
  • Octavin 2
  • Tierce 1-3/5
  • Plein Jeu III
  • Bombarde 16
  • Trompette 8
  • Hautbois 8
GERMAN BAROQUE
  • Lieblich Gedackt 16
  • Prinzipal 8
  • Holzgedackt 8
  • Gamba 8
  • Oktave 4
  • Flöte 4
  • Nasard 3
  • Waldflöte 2
  • Quinte 1-1/3
  • Scharff IV
  • Posaune 16
  • Trompete 8
  • Dulzian 8
VARIANT LIBRARY
  • Violon 16
  • Geigen Principal 8
  • Harmonic Flute 8
  • Flute Céleste II 8
  • Fugara 4
  • Rohrflute 4
  • Sesquialtera II
  • Italian Principal 2
  • Sifflöte 1
  • Ripieno IV
  • Basson 16
  • Basson 8
  • Vox Humana 8

CHOIR

AMERICAN ECLECTIC
  • Principal 8
  • Gedackt 8
  • Unda Maris II 8
  • Octave 4
  • Koppelflöte 4
  • Spitzflöte 2
  • Larigot 1-1/3
  • Scharff III
  • Clarinet 8
  • Festival Trumpet 8
  • Choir Orch A
  • Choir Orch B
  • Swell to Choir
  • Tremulant
ENGLISH CATHEDRAL
  • Diapason 8
  • Concert Flute 8
  • Gemshorn Céleste II 8
  • Principal 4
  • Orchestral Flute 4
  • Nachthorn 2
  • Nineteenth 1-1/3
  • Mixture III
  • English Horn 8
  • Royal Tuba 8
FRENCH ROMANTIC
  • Montre 8
  • Bourdon 8
  • Viola Céleste II 8
  • Prestant 4
  • Nachthorn 4
  • Piccolo 2
  • Quinte 1-1/3
  • Cymbel III
  • Cromorne 8
  • Trompette en Chamade 8
GERMAN BAROQUE
  • Spitz Prinzipal 8
  • Gedackt 8
  • Spitzgamba 8
  • Oktav 4
  • Blockflöte 4
  • Gemshorn 2
  • Sifflöte 1
  • Mixtur III
  • Krummhorn 8
  • Schalmey 8
VARIANT LIBRARY
  • Bach Principal 8
  • Gross Flute 8
  • Viola Pomposa 8
  • Musette 4
  • Unda Maris II 4
  • Doublette 2
  • Sept-Terz II
  • Sesquialter II
  • Bombarde 8
  • Corno di Bassetto 16

PEDAL

AMERICAN ECLECTIC
  • Contra Bourdon 32
  • Principal 16
  • Subbass 16
  • Octave 8
  • Bass Flute 8
  • Choral Bass 4
  • Mixture III
  • Bombarde 16
  • Trumpet 8
  • Pedal Orch A
  • Pedal Orch B
  • Great to Pedal
  • Swell to Pedal
  • Choir to Pedal
ENGLISH CATHEDRAL
  • Dbl. Open Diapason 32
  • Open Diapason 16
  • Bourdon 16
  • Diapason 8
  • Flute 8
  • Fifteenth 4
  • Mixture III
  • Trombone 16
  • Tromba 8
FRENCH ROMANTIC
  • Contra Violon 32
  • Contrebasse 16
  • Soubasse 16
  • Montre 8
  • Bourdon 8
  • Prestant 4
  • Plein Jeu III
  • Bombarde 16
  • Trompette 8
GERMAN BAROQUE
  • Untersatz 32
  • Prinzipalbass 16
  • Bordun 16
  • Oktave 8
  • Gedackt Bass 8
  • Oktave 4
  • Hintersatz III
  • Posaune 16
  • Trompete 8
VARIANT LIBRARY
  • Open Wood 32
  • Violone 16
  • Bourdon Doux 16
  • Violoncello 8
  • Lieblich Bourdon 8
  • Nachthorn 4
  • Clairon 4
  • Bass Clarinet 16
  • Trombone 8

INSPIRE SERIES 343

18 BUILT-IN ORCHESTRAL VOICES

Orchestral voices are accessed through any of the six Orchestral Couplers.

  • Piano
  • Elect. Piano
  • Harp
  • Harpsichord
  • Celesta
  • Strings
  • Slow Strings
  • Choir Oohs
  • Choir Aahs
  • Gospel Organ I
  • Gospel Organ II
  • Flute
  • Trumpet
  • Oboe
  • Clarinet
  • Handbells
  • Timpani
  • Chimes

음색

443 total voices
67 Main (75 Main including Library A/B couplers)
195 Voice Palette Stops
120 Organ Library stops and ensembles
61 Orchestral Library Voices
Chimes and Zimbelstern

건반 및 페달보드

AGO-standard velocity-sensitive keyboards and pedalboard

엄지 피스톤 THUMB PISTONS

12 General, 5 Great, 5 Swell, 5 Choir, 5 Solo, plus 51 functional controls

발 피스톤 TOE PISTONS

12 General, 5 Pedal, plus 7 functional controls

슈즈 SHOES

2 Expression and Crescendo

메모리 MEMORY

99 internal memory banks, unlimited with the USB drive

커플러 COUPLERS

Swell and Choir octave couplers; 8 Library/MIDI couplers; Bass, Swell, Choir, and Solo Melody couplers

트레뮬런트 TREMULANTS

Great, Swell, Choir, Solo, Main and Flute Tremulant Alternate
