인스파이어 시리즈 233

33 STOPS

영적 경험을 향상시키는 사운드

4가지 스타일과 최첨단 165가지 파이프 오르간 음색을 갖춘 로저스 인스파이어 시리즈 233은 영적인 경험을 향상시키기 위해 특별히 설계되었습니다. 오르간은 통합 2.1 오디오 시스템을 갖추고 있으며 외부 4.2 오디오 시스템으로 업그레이드할 수 있어 가정 및 소규모 홀에서 사용하거나 최대 200명까지 수용할 수 있는 교회에 이상적입니다.

혁신적인 보이스 팔레트 시스템

다양한 색상의 오크 디자인으로 제공되는 오르간은 2개의 키보드, 32음 페달보드 및 표준 스탑 목록에 있는 33개의 오리지널 음색을 갖추었습니다. 혁신적인 보이스 팔레트 (Voice Palette™) 시스템을 통해 다양한 스타일의 음색을 무한대로 조합할 수 있습니다. 로저스 인스파이어 시리즈 233은 어떤 스타일이든 연주할 수 있는 자유를 제공할 뿐만 아니라 천상의 음악에 영감을 주기 위해 설계되었습니다.

18 ORCHESTRAL VOICES

나만의 사운드스케이프 만들기

인스파이어 시리즈 233은 피아노, 하프, 현악기, 트럼펫, 클라리넷, 핸드벨 등 다양한 오케스트라 음색을 선택할 수 있습니다. 이러한 모든 가능성을 갖추어 무한한 영감을 북돋우는 천상의 사운드를 경험해보십시오.

최대 200명 수용 가능한
장소에 적합한 오르간

RODGERS_INSPIRE_SR227_DETAIL_7
RODGERS_INSPIRE_SR227_DETAIL_3
previous arrowprevious arrow
next arrownext arrow
Shadow

인스파이어 233 제원

제원
편의 사항
스탑 리스트
라이브러리

VOICES

27 stops / 153 total voices
4 unique organ styles + Variant Library
135 Voice Palette™ Voices
18 orchestral voices

KEYBOARDS

Velocity-sensitive “Pipe Organ Feel” tracker touch keyboards

PEDALBOARD

Velocity-sensitive
32-note AGO pedalboard

GENERAL PISTONS

10

TOE PISTONS

5 (9 more optional)

DIVISIONAL PISTONS

5 Great, 5 Swell

COUPLERS

3 (Great to Pedal, Swell to Pedal, Swell to Great)
6 Orchestral Couplers (2 x Great, 2 x Swell, 2x Pedal)
Bass Coupler
Melody Coupler

TREMULANTS

2 (Great, Swell)

SHOES

2 (programmable)

MEMORY

50 levels x 25 pistons (1250)

외형 치수

높이 : 118.5 cm
너비 : 152.4 cm
깊이 : 70.3 cm
깊이(페달보드 포함) : 116.8 cm

  • Traditional wood veneer cabinet with deluxe wood tambour
  • Available in light, medium and dark oak veneer
  • Tab stop controls
  • Record/playback with STOP, PLAY, REC pistons
  • USB-enabled for unlimited storage of registration data and saved performances
  • Hymn Player automatically plays 350 built-in hymns with introduction & verse or Prelude mode
  • Bench in matching finish
  • Rolltop + lock
  • 32-note radiating AGO pedalboard velocity-sensitive for orchestral voices
  • Self-contained pedalboard mechanism for greater reliability on uneven flooring or carpeting
  • Kick switch programmable as Off, Next, Prev, Sustain and Gospel Rotor for orchestral voices
  • Programmable pedal F# sustain function for orchestral voices
  • Memory +/- pistons
  • 9 historic temperaments
  • True Sound Space: 12 real reverb environments
  • 2.1-channel internal audio system: 2 channels x 50 watts fullrange audio + 1 channel x 160 watts subwoofer
  • MIDI In and Out connections
  • Stereo headphone jack
  • 2 x 1/4” Line inputs
  • 2 x 1/4” Line outputs
  • Tuning control
  • -6/+5 transposer
  • 5 loudspeakers using coaxials for a rich and highly defined sound
  • 8-channel external audio outputs
  • 2-channel audio system for external loudspeakers (optional)
  • Onboard voicing finishing and leveling controls
  • Pipe organ modeling technologies
  • Great/Pedal Enclosed
  • Organ Type piston instantly activates American Eclectic, English Cathedral, French Romantic or German Baroque stops
  • Adjustable tremulants

Great

AMERICAN ECLECTIC
  • Violone 16
  • Principal 8
  • Bourdon 8
  • Gamba 8
  • Erzähler Céleste II 8
  • Octave 4
  • Spitzflöte 4
  • Super Octave 2
  • Cornet V
  • Fourniture IV
  • Trumpet 8
  • Great Orch A
  • Great Orch B
  • Tremulant
  • Swell to Great
ENGLISH CATHEDRAL
  • Open Diapason 16
  • Open Diapason 8
  • Chimney Flute 8
  • Second Diapason 8
  • Salicional 8
  • Principal 4
  • Waldflute 4
  • Fifteenth 2
  • Cornet IV
  • Mixture IV
  • Tromba 8
FRENCH ROMANTIC
  • Montre 16
  • Montre 8
  • Bourdon 8
  • Flûte Harmonique 8
  • Gambe 8
  • Prestant 4
  • Flute Ouverte 4
  • Doublette 2
  • Cornet IV
  • Fourniture IV
  • Trompette 8
GERMAN BAROQUE
  • Prinzipal 16
  • Prinzipal 8
  • Rohrflöte 8
  • Quintatön 8
  • Salicional 8
  • Oktave 4
  • Gemshorn 4
  • Super Oktave 2
  • Kornett V
  • Mixtur VI
  • Trompete 8
VARIANT LIBRARY
  • Quintaton 16
  • Diapason 8
  • Clarabel Flute 8
  • Doppel Flute 8
  • Voix des Anges II 8
  • Harmonic Flute 4
  • Quint 2-2/3
  • Harmonic Piccolo 2
  • Terz 1-3/5
  • Cymbel III
  • Tuba 8

SWELL

AMERICAN ECLECTIC
  • Bourdon Doux 16
  • Diapason 8
  • Bourdon 8
  • Viole Céleste II 8
  • Octave 4
  • Flute Traverse 4
  • Nazard 2-2/3
  • Block Flute 2
  • Tierce 1-3/5
  • Plein Jeu IV
  • Double Trumpet 16
  • Trumpet 8
  • Oboe 8
  • Swell Orch A
  • Swell Orch B
  • Tremulant
ENGLISH CATHEDRAL
  • Bourdon 16
  • Horn Diapason 8
  • Stopped Diapason 8
  • Viola Céleste II 8
  • Octave 4
  • Flute 4
  • Quintflute 2-2/3
  • Lieblich Piccolo 2
  • Seventeenth 1-3/5
  • Mixture III
  • Trombone 16
  • Trumpet 8
  • Cornopean 8
FRENCH ROMANTIC
  • Dulciane 16
  • Montre 8
  • Bourdon 8
  • Voix Céleste II 8
  • Prestant 4
  • Flûte Octaviante 4
  • Nazard 2-2/3
  • Octavin 2
  • Tierce 1-3/5
  • Plein Jeu III
  • Bombarde 16
  • Trompette 8
  • Hautbois 8
GERMAN BAROQUE
  • Lieblich Gedackt 16
  • Prinzipal 8
  • Holzgedackt 8
  • Gamba 8
  • Oktave 4
  • Flöte 4
  • Nasard 3
  • Waldflöte 2
  • Quinte 1-1/3
  • Scharff IV
  • Posaune 16
  • Trompete 8
  • Dulzian 8
VARIANT LIBRARY
  • Violon 16
  • Geigen Principal 8
  • Harmonic Flute 8
  • Flute Céleste II 8
  • Fugara 4
  • Rohrflute 4
  • Sesquialtera II
  • Italian Principal 2
  • Sifflöte 1
  • Ripieno IV
  • Corno di Bassetto 16
  • Clarinet 8
  • Vox Humana 8

PEDAL

AMERICAN ECLECTIC
  • Contra Bourdon 32
  • Principal 16
  • Subbass 16
  • Octave 8
  • Bass Flute 8
  • Choral Bass 4
  • Mixture III
  • Bombarde 16
  • Trumpet 8
  • Pedal Orch A
  • Pedal Orch B
  • Great to Pedal
  • Swell to Pedal
ENGLISH CATHEDRAL
  • Dbl. Open Diapason 32
  • Open Diapason 16
  • Bourdon 16
  • Diapason 8
  • Flute 8
  • Fifteenth 4
  • Mixture III
  • Trombone 16
  • Tromba 8
FRENCH ROMANTIC
  • Contra Violon 32
  • Contrebasse 16
  • Soubasse 16
  • Montre 8
  • Bourdon 8
  • Prestant 4
  • Plein Jeu III
  • Bombarde 16
  • Trompette 8
GERMAN BAROQUE
  • Untersatz 32
  • Prinzipalbass 16
  • Bordun 16
  • Oktave 8
  • Gedackt Bass 8
  • Oktave 4
  • Hintersatz III
  • Posaune 16
  • Trompete 8
VARIANT LIBRARY
  • Open Wood 32
  • Violone 16
  • Bourdon Doux 16
  • Violoncello 8
  • Lieblich Bourdon 8
  • Nachthorn 4
  • Clairon 4
  • Bass Clarinet 16
  • Trombone 8

INSPIRE SERIES 233

18 BUILT-IN ORCHESTRAL VOICES

Orchestral voices are accessed through any of the six Orchestral Couplers.

  • Piano
  • Elect. Piano
  • Harp
  • Harpsichord
  • Celesta
  • Strings
  • Slow Strings
  • Choir Oohs
  • Choir Aahs
  • Gospel Organ I
  • Gospel Organ II
  • Flute
  • Trumpet
  • Oboe
  • Clarinet
  • Handbells
  • Timpani
  • Chimes

음색

443 total voices
67 Main (75 Main including Library A/B couplers)
195 Voice Palette Stops
120 Organ Library stops and ensembles
61 Orchestral Library Voices
Chimes and Zimbelstern

건반 및 페달보드

AGO-standard velocity-sensitive keyboards and pedalboard

엄지 피스톤 THUMB PISTONS

12 General, 5 Great, 5 Swell, 5 Choir, 5 Solo, plus 51 functional controls

발 피스톤 TOE PISTONS

12 General, 5 Pedal, plus 7 functional controls

슈즈 SHOES

2 Expression and Crescendo

메모리 MEMORY

99 internal memory banks, unlimited with the USB drive

커플러 COUPLERS

Swell and Choir octave couplers; 8 Library/MIDI couplers; Bass, Swell, Choir, and Solo Melody couplers

트레뮬런트 TREMULANTS

Great, Swell, Choir, Solo, Main and Flute Tremulant Alternate
