이매진 시리즈 351M

51 MAIN PIPE ORGAN STOPS

오르간의 걸작

로저스 이매진 시리즈 351M은 현장감 넘치는 리얼한 파이프 오르간 샘플링으로 청중과 오르간 연주자를 매료시킵니다. 오르간에는 Chimes와 Zimbelstern을 포함하여 51개의 메인 파이프 오르간 스탑이 준비되어 있습니다. 각 드로우노브는 4개의 선택 가능한 스탑이 있고, American Eclectic, English Cathedral, French Romantic 및 German Baroque의 4가지 고유한 오르간 스타일에 걸쳐 총 198개의 Voice Palette™ 방대한 스탑을 준비하고 있습니다.

오르간에는 클래식한 파이프 오르간의 느낌을 원하는 오르간 연주자를 위한 프리미엄 무빙 스탑과 탭이 장착되어 있습니다. 로저스 이매진 시리즈 351M은 비교할 수 없는 수준의 품질, 편안함 및 편의성을 제공합니다.

비교할 수 없는
다양성을 발견하십시오.

198개의 Voice Palette™ 스탑 외에도 사용자 지정 가능한 오르간 스탑 라이브러리는 88개의 파이프 오르간 스탑과 앙상블을 지닙니다. 또한 리얼한 악기 사운드로 가득 차 있는 오케스트라 라이브러리는 37개의 프리미엄 오케스트라 보이스가 탑재되어 있습니다. 오르간 연주자는 총 323개의 선택 항목을 손쉽게 사용할 수 있고 오르간 음악의 모든 스타일을 레지스트레이션에 사용자 정의할 수 있습니다.

오르간 레지스트레이션을 위한 무수한 가능성의 새로운 세계를 여는 실시간 스탑 셀렉션은 일반적인 디지털 오르간을 뛰어넘는 전문적인 믹스 앤 매치 기능을 가능하게 합니다. 강력한 초고속 컴퓨터 프로세서와 향상된 메모리를 탑재하여 매우 정교한 기술로 알려진 다이렉트 스트리밍을 가능하게 하며 원활한 통합을 제공합니다.

최고 수준으로
제작
되는 오르간

이매진 시리즈 오르간은 미국 오르가니스트 조합 (American Guild of Organists(AGO))의 표준에 따라 면밀한 검토를 거쳐 제작되었으며 우아한 디자인의 아름다운 콘솔을 선보입니다. 로저스 독점의 32노트 벨로시티 센서티브 AGO 페달 보드가 기본으로 탑재되고, 오케스트라 보이스를 위한 128레벨 벨로시티 센서티브가 탑재된 3개의 Performance TouchTM 벨로시티 센서티브 건반을 갖추었습니다. 또한 아름답게 빛나는 조명은 보면대, 피스톤, 드로우 노브, 탭 및 페달 조명이 오르가니스의 연주를 더욱 편하게 해줍니다.

첨단 기술의 집대성
오르간의 걸작

RODGERS_IMAGINE_351D_DETAIL_10
RODGERS_IMAGINE_351D_DETAIL_11
previous arrowprevious arrow
next arrownext arrow
Shadow

"최고의 악기"

우리 교회의 파이프 오르간을 개선하는 작업에 이매진 시리즈를 도입하여 대성공을 거두게 되어 기쁩니다.

브래들리 스워프

美 플로리다주 클리어워터 First United Methodist Church

이매진 351M 제원

제원
편의 사항
스탑 리스트
라이브러리

음색

198 Organ Stops (51 Main + 147 Voice Palette Stops)
88 Organ Library stops and ensembles
37 Orchestral Voices

DIVISIONAL PISTONS

5 Great, 5 Swell, 5 Choir, 5 Pedal

KEYBOARDS

Performance TouchTM velocity-sensitive keyboards

COUPLERS

6 plus 8 Library/MIDI Controls; Bass, Melody III Swell and Melody I Choir Couplers

SHOES

2 Expression, Crescendo2 Expression, Crescendo

PEDALBOARD

32-note radiating velocity-sensitive AGO pedalboard for expressive playing of onboard percussive voices such as piano, string bass, or timpani

메모리 MEMORY

50 levels per piston

GENERAL PISTONS

10

외형 치수

깊이 (페달 포함) : 1208.6 mm
깊이 (페달 제외) : 770.0 mm
높이 (보면대 포함 ) : 1511.0 mm
높이 (보면대 제외) : 1246.3 mm
너비 : 1625.0mm

TREMULANTS

10 configurable - optional 14

TREMULANTS

3 (Great, Swell, Choir) Tremulants + Flute Tremulant Alt

  • High-Resolution Color LCD Menu
  • Four-way adjustable Music Desk (Optional)
  • Built-in and conveniently located headphone jack for quiet practice
  • Dimmable illumination for the entire console
  • On-board Hymn Player with 350 hymns common to many denominations
  • USB storage for registration data and recorded performances
  • Built-in demo songs, including music for worship and standard organ literature
  • Easy-to-use record and playback system, storable to USB
  • Locking rolltop
  • Memory +/- pistons
  • Next piston
  • 10 standard toe pistons (up to 14 optional)
  • Built-in console speakers (optional 2 to 14 channel external audio systems)
  • Pipe compatibility with Rodgers Hybrid Organs
  • User-friendly transposer thumb pistons affect live performance, playback of recorded songs, or Hymn Player selections
  • Classic trim (Optional)
  • Deluxe adjustable bench (Optional)
  • 50 internal memory banks, unlimited memory banks with the USB drive
  • Configurable toe pistons to change the number order or the function
  • Programmable pedal F# sustain function and programmable kick-switch functions
  • Organ Type piston immediately accesses American Eclectic, English Cathedral, French Romantic and German Baroque organ styles
  • The Melody Coupler transmits Swell or Choir stops to the highest note played on the Great, providing ease of playing melody stops and Great accompaniment stops all on the Great manual. The Bass Coupler transmits Pedal stops to the lowest note played on the Great, providing an alternate way to play the pedals.
  • Flute Tremulant Alternate thumb piston offers a different tremulant rate for the Flute stops
  • 9 historic temperaments 12 real reverb environments MIDI In/Out and Local Off 2.1-channel internal audio system:
  • 2 channels x 50 watts full range audio + 1 channel x 160 watts subwoofer
  • 2 to 14 channel external audio option
  • Onboard voicing finishing and leveling controls
  • Pipe organ modeling technologies
  • Great/Pedal unenclosed thumb piston
  • Adjustable tremulants
  • Traditional wood veneer cabinet
  • with deluxe wood tambour
  • Music storage bench in matching finish
  • Self-contained pedalboard mechanism for greater reliability on uneven flooring or carpeting

Great

AMERICAN ECLECTIC
  • Violone 16’
  • Principal 8’
  • Chimney Flute 8’
  • Gemshorn 8’
  • Octave 4’
  • Spitzflute 4’
  • Quint 2 2/3’
  • Super Octave 2’
  • Cornet V
  • Fourniture IV
  • Trumpet 8’
  • Chimes
  • Zimbelstern
  • Library/MIDI A
  • Library/MIDI B
  • Tremulant
  • Swell to Great
  • Choir to Great
ENGLISH CATHEDRAL
  • Double Open Diapason 16’
  • Open Diapason 8’
  • Rohrflute 8’
  • Salicional 8’
  • Principal 4’
  • Waldflute 4’
  • Twelfth 2 2/3’
  • Fifteenth 2’
  • Cornet IV
  • Mixture IV
  • Tromba 8’
FRENCH ROMANTIC
  • Montre 16’
  • Montre 8’
  • Bourdon 8’
  • Gambe 8’
  • Prestant 4’
  • Flute Ouverte 4’
  • Quinte 2 2/3’
  • Doublette 2’
  • Cornet IV
  • Grand Fourniture IV
  • Trompette 8’
GERMAN BAROQUE
  • Prinzipal 16’
  • Prinzipal 8’
  • Rohrflöte 8’
  • Quintatön 8’
  • Oktave 4’
  • Gemshorn 4’
  • Nasat 2 2/3’
  • Super Oktave 2’
  • Kornett V
  • Mixtur VI
  • Trompete 8’



SWELL

AMERICAN ECLECTIC
  • Bourdon Doux 16’
  • Geigen Principal 8’
  • Bourdon 8’
  • Flûte Céleste II 8’
  • Viola Céleste II 8’
  • Octave 4’
  • Flute Traverse 4’
  • Nazard 2 2/3’
  • Octavin 2’
  • Tierce 1 3/5’
  • Plein Jeu IV
  • Double Trumpet 16’
  • Trumpet 8’
  • Oboe 8’
  • Clarion 4’
  • Library/MIDI A
  • Library/MIDI B
  • Tremulant
ENGLISH CATHEDRAL
  • Bourdon 16’
  • Horn Diapason 8’
  • Stopped Diapason 8’
  • Unda Maris II 8’
  • Viola Céleste II 8’
  • Octave Gamba 4’
  • Flute 4’
  • Quintflute 2 2/3’
  • Lieblich Piccolo 2’
  • Seventeenth 1 3/5’
  • Mixture III
  • Contra Trumpet 16’
  • Trumpet 8’
  • Cornopean 8’
  • Clairon 4’
FRENCH ROMANTIC
  • Dulciane 16’
  • Montre 8’
  • Traverse Flute 8’
  • Flûte Céleste II 8’
  • Voix Céleste II 8’
  • Prestant 4’
  • Flûte Octaviante 4’
  • Nasard 2 2/3’
  • Flute à Bec 2’
  • Tierce 1 3/5’
  • Fourniture III
  • Bombarde 16’
  • Trompette 8’
  • Hautbois 8’
  • Petite Clairon 4’
GERMAN BAROQUE
  • Lieblich Gedackt 16’
  • Prinzipal 8’
  • Holzgedackt 8’
  • Voce Umana 8’
  • Schwebung II 8’
  • Oktave 4’
  • Flöte 4’
  • Nasat 2 2/3’
  • Waldflöte 2’
  • Quinte 1 1/3’
  • Scharff IV
  • Posaune 16’
  • Trompete 8’
  • Dulzian 8’
  • Rohr Schalmei 4’

CHOIR

AMERICAN ECLECTIC
  • Principal 8’
  • Holzgedackt 8’
  • Erzähler Céleste II 8’
  • Octave 4’
  • Koppelflute 4’
  • Klein Octave 2’
  • Larigot 1 1/3’
  • Mixture IV
  • Corno di Bassetto 16’
  • Clarinet 8’
  • Festival Trumpet 8’
  • Library/MIDI A
  • Library/MIDI B
  • Tremulant
  • Swell to Choir
ENGLISH CATHEDRAL
  • Diapason 8’
  • Gedackt 8’
  • Muted Violins II 8’
  • Principal 4’
  • Orchestral Flute 4’
  • Super Octave 2’
  • Nineteenth 1 1/3’
  • Plein Jeu IV
  • Basson 16’
  • English Horn 8’
  • Royal Tuba 8’
FRENCH ROMANTIC
  • Montre 8’
  • Bourdon 8’
  • Dulcett Céleste II 8’
  • Prestant 4’
  • Nachthorn 4’
  • Italian Principal 2’
  • Quinte 1 1/3’
  • Cymbale III
  • Hautbois 16’
  • Bombarde 8’
  • Tromba del Giubileo 8’
GERMAN BAROQUE
  • Spitz Prinzipal 8’
  • Singendgedeckt 8’
  • Unda Maris II 8’
  • Oktave 4’
  • Blockflöte 4’
  • Oktave 2’
  • Oktave 1’
  • Zimbel IV
  • Dulzian 16’
  • Krummhorn 8’
  • Trompette en Chamade 8

PEDAL

AMERICAN ECLECTIC
  • Contra Bourdon 32’
  • Principal 16’
  • Subbass 16’
  • Violone 16’
  • Octave 8’
  • Bass Flute 8’
  • Choral Bass 4’
  • Mixture IV
  • Contra Bombarde 32’
  • Bombarde 16’
  • Trumpet 8’
  • Clarion 4’
  • Library/MIDI A
  • Library/MIDI B
  • Great to Pedal
  • Swell to Pedal
  • Choir to Pedal
ENGLISH CATHEDRAL
  • Open Wood 32’
  • Open Diapason 16’
  • Bourdon 16’
  • Lieblich Bourdon 16’
  • Diapason 8’
  • Flute 8’
  • Fifteenth 4’
  • Mixture III
  • Double Waldhorn 32’
  • Trombone 16’
  • Tromba 8’
  • Hautbois 4’
FRENCH ROMANTIC
  • Contra Violon 32’
  • Principal 16’
  • Soubasse 16’
  • Contre Basse 16’
  • Prestant 8’
  • Bourdon 8’
  • Prestant 4’
  • Plein Jeu III
  • Contre Hautbois 32’
  • Bombarde 16’
  • Trompette 8’
  • Clairon Harmonique 4’
GERMAN BAROQUE
  • Untersatz 32’
  • Prinzipalbass 16’
  • Bordun 16’
  • Grossgamba 16’
  • Oktave 8’
  • Gedeckt Bass 8’
  • Oktave 4’
  • Hintersatz III
  • Bombarde 32’
  • Posaune 16’
  • Trompete 8’
  • Rohr Schalmei 4’
RODGERS ORGAN AND ORCHESTRAL LIBRARY

로저스 이매진 시리즈 오르간에는 88개의 최신 오르간 스탑과 앙상블과 37개의 프리미엄 오케스트라 음색을 갖춘 내장형 오르간 및 오케스트라 라이브러리가 포함됩니다.

라이브러리는 디비전 당 두 개의 라이브러리/MIDI 컨트롤 중 하나를 통해 모든 매뉴얼 및 페달로 액세스할 수 있습니다. 각 선택은 유저 보이스로 조합이 가능하며 피스톤에 저장됩니다.

CLASSICAL ORGAN LIBRARY
  • 001 Principal 32’
  • 002 Contra Violone 32’
  • 003 Contra Bourdon 32’
  • 004 Diapente Grave 21 1/3
  • 005 Lieblich Gedackt 16’
  • 006 Dulciana 16’
  • 007 Open Wood 16’
  • 008 Spitzflute 16’
  • 009 Quint 10 2/3’
  • 010 English Diapason 8’
  • 011 Italian Principal 8’
  • 012 Gemshorn 8’
  • 013 Gamba 8’
  • 014 Gamba Celeste II 8’
  • 015 Aeoline 8’
  • 016 Flute Harmonique 8’
  • 017 Gross Flute 8’
  • 018 Quint 5 1/3’
  • 019 Oktav 4’
  • 020 Principal 4’
  • 021 Rohrflöte 4’
  • 022 Orchestral Flute 4’
  • 023 Unda Maris II 4’
  • 024 Gross Tierce 3 1/5’
  • 025 Violetta in Quinta 2 2/3’
  • 026 Principal 2’
  • 027 Salicional 2’
  • 028 Piccolo 2’
  • 029 Tierce 1 3/5’
  • 030 Larigot 1 1/3’
  • 031 Septième 1 1/7’
  • 032 Sifflöte 1’
  • 033 Jeu de Clochette II’
  • 034 Grave Cornet V
  • 035 Tertian II
  • 036 Pedal Grand Mixtur VI
  • 037 Harmonics V
  • 038 Tierce Fourniture VI
  • 039 Grand Mixtur IV-VIII
  • 040 Klein Mixture III
  • 041 Double Ophicleide 32’
  • 042 Contre Bombarde 32’
  • 043 Contra Fagott 16’
  • 044 Pontifical Trumpet 16’
  • 045 Rankett 16’
  • 046 Trompet 8’
  • 047 2nd Trompette 8’
  • 048 French Horn 8’
  • 049 Hautbois 8’
  • 050 Rohr Schalmei 8’
  • 051 Dulzian 8’
  • 052 Cromorne 8’
  • 053 Oboe 8’
  • 054 Regal 8’
  • 055 Vox Humana 8’
  • 056 Vox Humaine 8’
  • 057 Tuba Mirabilis 8’
  • 058 State Trumpet 8’
  • 059 Chamades 8’
  • 060 Trumpet De Fete 8’
  • 061 Clarion 4’
  • 062 2nd Clairon 4’
  • 063 Schalmei 4’
  • 064 16+4 Flute Céleste IV
  • 065 16+4 Célestes IV
  • 066 16+8+4 Célestes VI
  • 067 16+8+4+Célestes+Vox H
  • 068 Barker Noise
THEATER ORGAN LIBRARY
  • 200 16+8 Voxes II
  • 201 16+4 Voxes II
  • 202 8 Tibia
  • 203 4 Tibia
  • 204 8 Viol D’Orchestre II
  • 205 8 Viol D’Orchestre II Trem
  • 206 8 Tuba Trem
  • 207 8 Cornopean Trem
  • 208 Tibia 16+8+Vox 16+8
  • 209 Tibia 16842+Strings
  • 210 Tibia 84+Quint+Vox+Cel
  • 211 Vox 16+8+Célestes
  • 212 Tibia 84+VDO Cel
  • 213 Tibia 84+Vox+Célestes
  • 214 Tibia 84+Célestes+Tuba
  • 215 Tibia 4+Célestes 8
  • 216 Tibia 42+Strings 168
  • 217 Tibia 4+Kinura 8
  • 218 Strings 8+Tibia 2+Glock
  • 219 Tibia 4+Glock
ORCHESTRAL LIBRARY
  • 300 Grand Piano
  • 301 Electric Piano
  • 302 Harpsichord 8
  • 303 Harpsichord 4
  • 304 Harpsichord Lute
  • 305 Harpsichord 8+4
  • 306 Celesta
  • 307 Xylophone
  • 308 Orchestral Harp
  • 309 Drawbars 1
  • 310 Drawbars 2
  • 311 Guitar
  • 312 Acoustic Bass
  • 313 String Ensemble
  • 314 Orchestra
  • 315 Slow Strings
  • 316 Octave Strings
  • 317 Violin
  • 318 Saxophone
  • 319 Orchestral Trumpet
  • 320 Trombone
  • 321 Bright Brass
  • 322 Brass Ensemble
  • 323 French Horn
  • 324 Tuba
  • 325 Orchestral Flute
  • 326 Bagpipes
  • 327 Panpipes
  • 328 Orchestral Oboe
  • 329 Orchestral Clarinet
  • 330 Bandoneon
  • 331 Choir Aahs
  • 332 Choir Oohs
  • 333 Organ Chimes
  • 334 Tubular Bells
  • 335 Handbells
  • 336 Timpani

음색

443 total voices
67 Main (75 Main including Library A/B couplers)
195 Voice Palette Stops
120 Organ Library stops and ensembles
61 Orchestral Library Voices
Chimes and Zimbelstern

건반 및 페달보드

AGO-standard velocity-sensitive keyboards and pedalboard

엄지 피스톤 THUMB PISTONS

12 General, 5 Great, 5 Swell, 5 Choir, 5 Solo, plus 51 functional controls

발 피스톤 TOE PISTONS

12 General, 5 Pedal, plus 7 functional controls

슈즈 SHOES

2 Expression and Crescendo

메모리 MEMORY

99 internal memory banks, unlimited with the USB drive

커플러 COUPLERS

Swell and Choir octave couplers; 8 Library/MIDI couplers; Bass, Swell, Choir, and Solo Melody couplers

트레뮬런트 TREMULANTS

Great, Swell, Choir, Solo, Main and Flute Tremulant Alternate
